Typically made from high-quality carbon steel, stainless steel, or other alloys, BS 10 Table F Flanges are designed to provide strength and resist corrosion. They are engineered to handle high-pressure and moderate-temperature conditions. Their mechanical properties boast impressive tensile strength, good impact resistance, and outstanding durability. These flanges are user-friendly, making installation and maintenance a breeze, while ensuring precise alignment and leak-proof connections. Their robust construction guarantees optimal performance even in the most demanding applications.
Vishal Flanges, a leading supplier in Delhi, India, offers an extensive selection of BS 10 Table F Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size | (1/2″) To (48″) |
|---|---|
| Size Of Bore Diameter Flange | NPS ≤ 10 |
| Standard Dimensions | EN-1092, ASME B16.48, API605, BS4504, EN1092, UNI, ISO, API7S-43, ANSI/ASME B16.5, API7S-15, MSS S44, IS 2062, ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, ISO70051, API. |
| Minimum Pressure | 150# To 2500# |
| Flange Face Type Manufacturer | Raised Face, Groove And Small Tongue Groove, RTJ, Flat Face, Large Tongue & Large Male-Female And Small Male-Female, Lap-Joint Face. |
| Top Six Type Of Flange | Threaded Flange, Lap Joint Flange, Socket-Weld Flange, Blind Flange, Slip-On Flange, Weld Neck Flange |
| Standard Materials | Duplex Steel & Super Duplex Steel, Copper Nickel, Inconel, Mild Steel, Stainless Steel, Hastelloy, Alloy Steel, Carbon Steel. |
| Thickness Length | NPS ≤ 18 |
| Manufacturing Process | Forged/ Machined/ Heat Treated |
| Other Type Of Flange | Forged/ Plate/ Threaded |
| Normal Pipe Size | A | D | L | K | C | B | H1 | H2 | N1 | N2 | R1 | R2 | HOLES | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | Millimeter | |||||||||||||
| ½” | 15 | 21.3 | 95.3 | 14.5 | 66.8 | 6.4 | 22.4 | 9.5 | 22.2 | 27.0 | 33.3 | 6.4 | 1.6 | 4 |
| ¾” | 20 | 26.7 | 101.6 | 14.5 | 73.2 | 6.4 | 27.7 | 11.1 | 22.2 | 33.3 | 38.1 | 6.4 | 1.6 | 4 |
| 1″ | 25 | 33.5 | 114.3 | 14.5 | 82.6 | 7.2 | 34.6 | 11.1 | 22.2 | 42.9 | 47.6 | 6.4 | 1.6 | 4 |
| 1 ¼” | 32 | 42.2 | 120.7 | 14.5 | 87.4 | 7.9 | 43.2 | 11.1 | 25.4 | 49.2 | 55.6 | 6.4 | 1.6 | 4 |
| 1 ½” | 40 | 48.3 | 133.4 | 14.5 | 98.6 | 8.7 | 49.5 | 12.7 | 28.6 | 58.7 | 61.9 | 6.4 | 1.6 | 4 |
| 2″ | 50 | 60.5 | 152.4 | 17.5 | 114.3 | 9.5 | 62.0 | 12.7 | 28.6 | 69.9 | 74.6 | 6.4 | 1.6 | 4 |
| 2 ½” | 65 | 73.2 | 165.1 | 17.5 | 127.0 | 10.3 | 74.7 | 15.9 | 31.8 | 82.6 | 90.5 | 6.4 | 1.6 | 4 |
| 3″ | 80 | 88.9 | 184.2 | 17.5 | 146.1 | 11.1 | 90.7 | 15.9 | 34.9 | 101.6 | 106.4 | 6.4 | 1.6 | 4 |
| 3 ½” | 88 | 101.6 | 203.2 | 17.5 | 165.1 | 11.9 | 103.4 | 17.5 | 34.9 | 114.3 | 119.1 | 6.4 | 1.6 | 4 |
| 4″ | 100 | 114.3 | 215.9 | 17.5 | 177.8 | 12.7 | 116.1 | 19.1 | 41.3 | 130.2 | 133.4 | 9.5 | 3.2 | 4 |
| 5″ | 125 | 141.2 | 254.0 | 17.5 | 209.6 | 14.3 | 143.8 | 19.1 | 44.5 | 152.4 | 160.3 | 9.5 | 3.2 | 8 |
| 6″ | 150 | 168.4 | 279.4 | 17.5 | 235.0 | 17.5 | 171.7 | 19.1 | 47.6 | 184.2 | 185.7 | 9.5 | 3.2 | 8 |
| 8″ | 200 | 219.2 | 336.6 | 17.5 | 292.1 | 19.1 | 221.5 | 22.2 | 50.8 | 241.3 | 241.3 | 9.5 | 3.2 | 8 |
| 10″ | 250 | 273.1 | 406.4 | 22.2 | 355.6 | 22.2 | 276.4 | 27.0 | 63.5 | 292.1 | 298.5 | 9.5 | 3.2 | 8 |
| Standard | Class | Diameter | Bolt Circle Diameter | Number of Bolts | Bolt Size | Diameter of Bolt Hole |
| AS4087 Flanges | PN14 Flanges | 95 | 67 | 4 | M12 | 14 |
| AS 2129 Flange | Table C Flanges | 95 | 67 | 4 | 13 | 14 |
| Table F Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table E Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table F Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table H Flanges | 114 | 83 | 4 | 16 | 17 | |
| Table J Flanges | 114 | 83 | 4 | 16 | 17 | |
| ANSI B16.5 Flanges | ANSI 150 Flanges | 89 | 60 | 4 | 13 | 16 |
| ANSI 300 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 600 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 900 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ANSI 1500 Flanges | 121 | 83 | 4 | 19 | 22 | |
| BS 10 (DIN) Flange | PN6 Flanges | 80 | 55 | 4 | M10 | 11 |
| PN10 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN16 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN20 Flanges | 90 | 60.5 | 4 | M14 | 16 | |
| PN25 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN40 Flanges | 95 | 65 | 4 | M12 | 14 |
BS 10 Table F Flanges are widely utilized in industries that require high-pressure handling capabilities. You’ll often find them in oil and gas pipelines, petrochemical plants, and water treatment facilities. Additionally, these flanges are essential in HVAC systems, marine engineering, and fire protection systems, thanks to their reliability and strong performance. With their ability to maintain secure and leak-proof connections under pressure, BS 10 Table F Flanges are perfect for applications that demand durable piping connections in both industrial and commercial environments.
Yes, we offer custom sizes for BS 10 Table F Flanges to meet specific project needs. Our team at Vishal Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@vishalflanges.co.in.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
