Carbon Steel Orifice Flanges Manufacturer and Supplier in Delhi, India

Vishal Flanges, based in Delhi, India, has earned a solid reputation as a reliable manufacturer and supplier of Carbon Steel Orifice Flanges. These flanges are crafted with precision and built to last, playing a vital role in flow measurement and control applications. Renowned for their sturdy construction and dependable performance, the products from Vishal Flanges meet international quality standards. With state-of-the-art manufacturing facilities and a focus on customer satisfaction, we provide tailored solutions for a range of industries, including oil and gas, petrochemical, and power generation, ensuring consistent performance in critical applications.

Carbon Steel Orifice Flanges India, Price of Inconel Orifice Flanges, Carbon Steel Orifice Flanges Exporter in India, Carbon Steel Orifice Flanges Stockist in India, Carbon Steel Orifice Flanges Exporter in India, Carbon Steel Orifice Flanges Suppliers in Delhi, Carbon Steel Orifice Flanges Price in India, List in India, Carbon Steel Orifice Flanges Delhi

Carbon Steel Orifice Flanges

CS Orifice Flanges

Carbon Steel Orifice Raised Face Flanges

Our Carbon Steel Orifice Flanges are crafted from high-quality carbon steel, primarily made up of iron and carbon, with small amounts of manganese, silicon, and sulfur. These flanges boast impressive tensile strength, impact resistance, and ductility. Their mechanical properties guarantee reliable performance even under high-pressure and high-temperature conditions. Built to endure wear and tear, they offer exceptional durability and stress resistance, making them perfect for challenging industrial settings.

Carbon Steel Orifice Flanges Exporters in India, Carbon Steel Orifice Flanges Manufacturers in Delhi, Carbon Steel Orifice Flanges Weight Chart in Delhi, Carbon Steel Orifice Flanges Weight Chart, Carbon Steel Orifice Flanges Supplier in Delhi, Carbon Steel Orifice Flanges Supplier in India, Carbon Steel Orifice Flanges Stockists in Delhi, Carbon Steel Orifice Flanges Price, Carbon Steel Orifice Flanges Supplier in Delhi

Largest Carbon Steel Orifice Flanges Supplier in Delhi, India

Vishal Flanges, a premier supplier in Delhi, India, specializes in high-quality Carbon Steel Orifice Flanges, valued for their exceptional durability, corrosion resistance, precise engineering, and suitability across diverse industrial applications.

Contact us to get a quick quote for your requirement.

We offer These Flanges as per DIN, ISO, JIS or ANSI Standard.

Carbon Steel Orifice Flanges Specification

Carbon Steel Orifice Flanges Specifications: ASTM A105/ ASME SA105

Carbon Steel Orifice Flanges Dimensions: ANSI/ASME B16.36, Series A & B, BS4504, BS 10, EN-1092, DIN, etc.

Carbon Steel Orifice Flanges Standard: ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.

Carbon Steel Orifice Flanges : Size :1/2″ (15 NB) to 48″ (1200NB)

Carbon Steel Orifice Flanges Class / Pressure: 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.

Carbon Steel Orifice Flange Face Type: Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

Carbon Steel Orifice Flanges dimensions

Size in Inch	Size in mm	Outer Dia.	Flange Thick.	Hub OD	Weld Neck OD	Welding Neck Length	RF Dia.	RF Height	PCD	Orifice Hole dia	No of Bolts	Bolt Size UNC	RF Stud Length	Hole Size	ISO Stud Size	Weight in kg
		A	B	C	D	E	F	G	H	I
1	25	125	36.6	54	33.4	81	50.8	2	88.9	6.4	4	5/8	125	3/4	M16	4.5
1 1/2	40	155	36.6	70	48.3	84	73	2	114.3	6.4	4	3/4	135	7/8	M20	6.5
2	50	165	36.6	84	60.3	84	92.1	2	127	6.4	8	5/8	125	3/4	M16	7
2 1/2	65	190	36.6	100	73	87	104.8	2	149.2	6.4	8	3/4	135	7/8	M20	7.5
3	80	210	36.6	117	88.9	87	127	2	168.3	9.5	8	3/4	135	7/8	M20	9.4
4	100	255	36.6	146	114.3	90	157.2	2	200	12.7	8	3/4	135	7/8	M20	13.2
6	150	320	36.6	206	168.3	98	215.9	2	269.9	12.7	12	3/4	135	7/8	M20	14.6
8	200	380	39.7	260	219.1	110	269.9	2	330.2	12.7	12	7/8	145	1	M24	30
10	250	445	46.1	321	273	116	323.8	2	387.3	12.7	16	1	165	1 1/8	M27	41
12	300	520	49.3	375	323.8	129	381	2	450.8	12.7	16	1 1/8	180	1 1/4	M30	62
14	350	585	52.4	425	355.6	141	412.8	2	514.4	12.7	20	1 1/8	185	1 1/4	M30	84
16	400	650	55.6	483	406.4	144	469.9	2	571.5	12.7	20	1 1/4	195	1 3/8	M33	111
18	450	710	58.8	533	457	157	533.4	2	628.6	12.7	24	1 1/4	205	1 3/8	M33	138
20	500	775	62	587	508	160	584.2	2	685.8	12.7	24	1 1/4	215	1 3/8	M33	171
24	600	915	68.3	702	610	167	692.2	2	812.8	12.7	24	1 1/2	240	1 5/8	M39	247

Carbon Steel Orifice Flanges find extensive use in industries that demand precise flow measurement and control, such as oil and gas, chemical processing, and water treatment. They are a key component of orifice meter assemblies, enabling accurate flow rate calculations in pipelines. Perfect for high-pressure and high-temperature systems, these flanges are commonly used in refineries, power plants, and various process industries. Their strength and adaptability make them a top choice for applications that require secure and efficient fluid flow management.

Carbon Steel Orifice Flanges Stockist in Delhi, Carbon Steel Orifice Flanges Delhi, Carbon Steel Orifice Flanges Exporters in India, Carbon Steel Orifice Flanges Price List, Carbon Steel Orifice Flanges Price List in India, Carbon Steel Orifice Flanges Manufacturer in India, Carbon Steel Orifice Flanges Price List in Delhi

Types of Carbon Steel Orifice Flanges

Are Custom Sizes Available for Carbon Steel Orifice Flanges?

Yes, we offer custom sizes for Carbon Steel Orifice Flanges to meet specific project needs. Our team at Vishal Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@vishalflanges.co.in.

Material Testing

We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
