DIN 2633 PN16 Weld Neck Flanges Manufacturer and Supplier in Delhi, India

Vishal Flanges, based in Delhi, India, is a reputable manufacturer and supplier of DIN 2633 PN16 Weld Neck Flanges. These flanges are crafted to provide secure and sturdy connections, making them perfect for high-performance applications across various industries. Renowned for their precision, durability, and adherence to international standards, our DIN 2633 PN16 Weld Neck Flanges deliver outstanding reliability. With a strong emphasis on quality and customer satisfaction, Vishal Flanges offers top-notch solutions tailored to meet the unique needs of different industrial applications.

DIN 2633 PN16 Standards Weld Neck Flanges in Delhi, DIN 2633 PN16 Weld Neck Plate Flange in Delhi, Raised Face DIN 2633 PN16 WNRF Flanges in Delhi, Stainless Steel DIN 2633 PN16 Weld Neck Flanges in India, DIN 2633 PN16 Welding Neck Pipe Flange in India, Best Price of DIN 2633 PN16 Weld Neck Flange Manufacturer in India.

Stainless Steel DIN 2633 PN16 Weld Neck Flanges

Alloy Steel DIN 2633 PN16 Weld Neck Flanges

Alloy 20 DIN 2633 PN16 Weld Neck Flanges

Typically made from high-quality carbon steel, stainless steel, or alloy steel, DIN 2633 PN16 Weld Neck Flanges boast excellent tensile strength, durability, and resistance to corrosion. Rated for a pressure of 16 bar, these flanges provide exceptional mechanical stability and performance even in challenging conditions. The welded neck design improves load-bearing capacity and stress distribution, making them ideal for high-pressure and high-temperature systems.

Monel DIN 2633 PN16 WNRF Flange in India, Hastelloy DIN 2633 PN16 Weld Neck Flanges in Delhi, Titanium DIN 2633 PN16 Welding Neck Flanges in India, SS DIN 2633 PN16 Weld Neck Flanges Stockist in Delhi, Nickel Alloy DIN 2633 PN16 Weld Neck Flanges in Delhi, Inconel DIN 2633 PN16 WNRF Flanges in India, Alloy Steel DIN 2633 PN16 Weld Neck Flanges, Duplex Steel DIN 2631 Weld Neck Flange, Carbon Steel DIN 2633 PN16 Welding Neck Flanges in Delhi.

DIN 2633 PN16 Weld Neck Flanges Specification

Size Chart	1/2″ (15 NB) To 48″ (1200NB)
Coating Flanges Faces	Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint
Design For Size	DIN, EN, ASA, PN, JIS, BS, ANSI, ASME
Pressure Rating Table	Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS
Supporting Flanges Material	Flanges Bolts, Gasket, Ring Joint
Connect Type Type	FF, RTJ, SMF, LMF, RF, LJF
Production Process	Forged, Heat Treated and Machined
Standard	ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange
Machining Equipment	Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc

DIN 2633 PN16 Weld Neck Flanges Dimensions

Germany standard flange DIN 2633 welding neck flanges; nominal pressure 16
Brides à souder à collerette DIN 2633: pression nominale 16
Pipe			Flange				Neck				Raised face		Screws			Weight
																(7,85 Kg/dm3)
Rated	d1		D	b	k	h1	d3	s	r	h2	d4	f	Holes	Thread	d2	Kg
Diameter	ISO Series	DIN Series
15	–	20	95	14	65	35	30	2	4	6	45	2	4	M 12	14	0,648
	21,3	–					32
20	–	25	105	16	75	38	38	2,3	4	6	58	2	4	M 12	14	0,952
	26,9	–					40
25	–	30	115	16	85	38	42	2,6	4	6	68	2	4	M 12	14	1,14
	33,7	–					45
32	–	38	140	16	100	40	52	2,6	6	6	78	2	4	M 16	18	1,69
	42,4	–					56
40	–	44,5	150	16	110	42	60	2,6	6	7	88	3	4	M 16	18	1,86
	48,3	–					64
50	–	57	165	18	125	45	72	2,9	6	8	102	3	4	M 16	18	2,53
	60,3	–					75
65	76,1	–	185	18	145	45	90	2,9	6	10	122	3	4	M 16	18	3,06
80	88,9	–	200	20	160	50	105	3,2	8	10	138	3	8	M 16	18	3,7
100	–	108	220	20	180	52	125	3,6	8	12	158	3	8	M 16	18	4,62
	114,3	–					131
125	–	133	250	22	210	55	150	4	8	12	188	3	8	M 16	18	6,3
	139,7	–					156
150	–	159	285	22	240	55	175	4,5	10	12	212	3	8	M 20	22	7,75
	168,3	–					184
(175)	193,7	–	315	24	270	60	210	5,4	10	12	242	3	8	M 20	22	9,85
200	219,1	–	340	24	295	62	235	5,9	10	16	268	3	12	M 20	22	11
250	–	267	405	26	355	70	285	6,3	12	16	320	3	12	M 24	26	15,6
	273	–					292
300	323,9	–	460	28	410	78	344	7,1	12	16	378	4	12	M 24	26	22
350	355,6	–	520	30	470	82	390	8	12	16	438	4	16	M 24	26	31,2
	–	368														28,8
400	406,4	–	580	32	525	85	445	8	12	16	490	4	16	M 27	30	39,3
	–	419														36,3
(450)	457	–	640	34	585	85	490	8	12	16	550	4	20	M 27	30	44,3
500	508	–	715	34	650	90	548	8	12	16	610	4	20	M 30	33	61
600	610	–	840	36	770	95	652	8,8	12	18	725	5	20	M 33	36	75,4
700	711	–	910	36	840	100	755	8,8	12	18	795	5	24	M 33	36	77
800	813	–	1025	38	950	105	855	10	12	20	900	5	24	M 36	39	101
900	914	–	1125	40	1050	110	955	10	12	20	1000	5	28	M 36	39	122
1000	1016	–	1255	42	1170	120	1058	10	16	22	1115	5	28	M 39	42	162

Largest DIN 2633 PN16 Weld Neck Flanges Supplier in Delhi, India

Vishal Flanges, a leading supplier in Delhi, India, offers an extensive selection of DIN 2633 PN16 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.

Contact us to get a quick quote for your requirement.

We offer These Flanges as per DIN, ISO, JIS or ANSI Standard.

Vishal Flanges’ DIN 2633 PN16 Weld Neck Flanges are widely utilized in sectors like oil and gas, chemical processing, power generation, and water treatment facilities. They ensure reliable connections for pipelines, valves, and other equipment, guaranteeing leak-proof performance in high-pressure settings. Their robust design and impressive corrosion resistance make them perfect for transporting fluids, steam, and gases in critical systems. With their precision-engineered construction, they are the go-to choice for applications that demand strength, reliability, and durability.

DIN 2633 PN16 Welding Neck Flanges Stockist in India, DIN 2633 PN16 Weld Neck Flanges Supplier in Delhi, DIN 2633 PN16 Weld Neck Flanges Supplier in Delhi, DIN 2633 PN16 Welding Neck Flanges Stockist in Delhi, DIN 2633 PN16 Weld Neck Flanges Manufacturer in MM, DIN 2633 PN16 WNRF Flanges Manufacturer in India.

Types of DIN 2633 PN16 Weld Neck Flanges

Are Custom Sizes Available for DIN 2633 PN16 Weld Neck Flanges?

Yes, we offer custom sizes for DIN 2633 PN16 Weld Neck Flanges to meet specific project needs. Our team at Vishal Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@vishalflanges.co.in.

DIN 2633 PN16 Weld Neck Flanges Size Chart

NPS NPS (inch)
NPS NPS (inch)	Diammeter of Flange (inch)	No. of Bolts	Diammeter of Bolts (inch)	Diammeter of Bolt Holes (inch)	Bolt Circle (inch)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Widest Range of DIN 2633 PN16 Weld Neck Flanges in India.

DIN 2633 PN16 Weld Neck Flange Dimensions	Raised Face DIN 2633 PN16 Weld Neck Flange Manufacturer
DIN 2633 PN16 Weld Neck Flange Manufacturer	Flat Face DIN 2633 PN16 Weld Neck Flange Manufacturer
30 inch DIN 2633 PN16 Weld Neck Flange Dealer	Raised Face DIN 2633 PN16 Weld Neck Flanges Manufacturer
DIN 2633 PN16 Weld Neck Pipe Flanges Wholesaler	DIN 2633 PN16 WNRF Flanges Supplier
DIN 2633 PN16 WNRF Flange Stockist in India	Raised Faced DIN 2633 PN16 Slip-On flanges Dealer in India
Raised Face DIN 2633 PN16 Weld Neck Plate Flanges	Titanium DIN 2633 PN16 Welding Neck Flanges
18 inch DIN 2633 PN16 Carbon Steel Weld Neck Flange	DIN 2633 PN16 Weld Neck Flange Dimensions in mm
DIN 2633 PN16 WNRF Flanges Supplier in Delhi	Alloy Steel DIN 2633 PN16 Weld Neck Flanges Manufacturer in Delhi
Nickel Alloy DIN 2633 PN16 Welding Neck Flange	Mild Steel DIN 2633 PN16 Weld Neck Flange
Alloy Steel DIN 2633 PN16 Welding Neck Flanges	Copper Nickel DIN 2633 PN16 Weld Neck Flanges at Best Price
DIN 2633 PN16 Welding Neck FF Flange Supplier	Suppliers of DIN 2633 PN16 Weld Neck Flange
DIN 2633 PN16 WNRF Flanges Distributor in India	Flat Face DIN 2633 PN16 Weld Neck Flanges Exporter
DIN 2633 PN16 Welding Neck Flanges Supplier in Delhi	MS DIN 2633 PN16 Weld Neck Flange
DIN 2633 PN16 Large Diameter Weld Neck Flange	30 Inch DIN 2633 PN16 Weld Neck Pipe Flange Dimensions
8 Inch DIN 2633 PN16 Welding Neck Pipe Flanges	DIN 2633 PN16 Weld Neck Flanges Stockist
Carbon Steel Raised Face DIN 2633 PN16 Weld Neck Flange Stockist	Duplex Steel DIN 2633 PN16 WNRF Flanges Supplier in Delhi
ASME SA105N Raised Faced DIN 2633 PN16 Weld Neck Flanges	18 inch Carbon Steel DIN 2633 PN16 Weld Neck Flange
Carbon Steel DIN 2633 PN16 Welding Neck Flange	DIN 2633 PN16 Weld Neck RF Flange Supplier
DIN 2633 PN16 Weld Neck Pipe Flanges Supplier in Delhi	Duplex Steel DIN 2633 PN16 Weld Neck Flanges
4 inch Stainless Steel DIN 2633 PN16 Weld Neck Flange	DIN 2633 PN16 Weld Neck RF Flanges Stockholder
Stainless Steel DIN 2633 PN16 Weld Neck Flange	ASTM B564 Raised Faced DIN 2633 PN16 Weld Neck Flanges
DIN 2633 PN16 WNRF Flange Exporter	DIN 2633 PN16 Weld Neck Flange Pressure Ratings
German Standard DIN 2633 PN16 Weld Neck Flanges	DIN 2633 PN16 Weld Neck Flange Supplier in India

Material Testing

We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
